Volkswagen VW Transporter T5 (Diesel) 2003 – 2014 Haynes Owners Service Repair Manual covers VW Transporter T5 variants with diesel engines and front-wheel-drive.Engines Covered: Diesel: 1.9 litre (1896cc) 2.0 litre (1968cc) 2.5 litre (2461cc)DOES NOT cover petrol engined models twin turbo diesel engine DSG transmission all-wheel-drive Syncro models or specialist bodywork/camper conversionsContents: Living with Your VW Transporter Roadside Repairs Weekly Checks Lubricants Fluids Tyre Pressures Routine Maintenance Service 1.9 litre Engine In-Vehicle Repair Procedures 2.0 Engine In-Vehicle Repair Procedures 2.5 Engine In-Vehicle Repair Procedures Engine Removal and Overhaul Procedures Cooling Heating Ventilation Systems Fuel Exhaust Systems – 1.9 2.5 Engines Fuel Exhaust Systems – 2.0 Engine Emission Control Systems Starting Charging Systems Ignition System Clutch Manual Gearbox Automatic Transmission Driveshafts Braking System Suspension Steering Bodywork Fittings Body Electrical Systems Wiring DiagramsNOTE: Only maintenance adjustment minor repair procedures plus removal and installation are described for the Transmissions. further data
