Honda XR600R 1991 – 2000 and XR650L 1993 – 2007Clymer Owners Service and Repair Manual

click here to learn more
Softcover – 323 pages – Honda XR600R 1991 – 2000 XR650L 1993 – 2007 Clymer Owners Service Repair Manual covers Honda XR600R 1991-2000 and XR650L 1993-2007 dirt bikes equipped with Radial Four Valve Combustion (RFVC) air-cooled four-stroke single-cylinder engines.Note: the Honda XR650R 2000 – 2007 Manual is covered in the Clymer CM225 manualContents: Quick Reference Data General InformationManual organization / Warnings cautions and notes / Safety / Serial numbers and information labels / Fasteners / Shop supplies / Tools / Measuring tools / Electrical system fundamentals / Service methods / Storage / Specifications TroubleshootingElectrical component replacement / Starting the engine / Engine will not start / Poor engine performance / Fuel system / Engine / Engine lubrication / Leakdown test / Clutch / Gearshift linkage / Transmission / Electrical testing / Starting system (XR650L) / Charging system (XR650L) / Ignition system / Front suspension and steering / Rear suspension / Brakes Lubrication Maintenance and Tune-UpPre-ride inspection / Engine oil / Oil line strainer / Oil strainer screen / Air filter / Control cable inspection and lubrication / Clutch lever adjustment / Drive chain / Wheel bearing inspection / Emission control system (XR650L) / Spark plug / Valve clearance adjustment / Starter decompression lever adjustment (XR600R) / Compression test / Tune up Engine Top EndCylinder head cover and camshaft / Camshaft chain tensioner / Cylinder head / Valves and components / Cylinder / Piston pin and rings Engine Lower EndEngine removal-installation / Starter gear assembly / Flywheel and starter clutch / Kickstarter / Oil pump / Oil lines / Oil strainer screen / Primary drive gear / Camshaft chain and guides / Crankcase and crankshaft / Break-in Clutch and External Shift MechanismClutch cable / Right crankcase cover / Clutch release lever / External shift mechanism Transmission and Internal Shift MechanismInternal shift mechanism Fuel Emmision Control and Exhaust SystemsCarburetor / Adjustments / Throttle cable / Choke cable / Fuel tank / Fuel valve / Crankcase breather system / Evaporative emission control system / Pulse seondary air injection system / Air box Electrical SystemCharging system / Alternator / Voltage regulator-rectifier / Ignition system / Ignition control module / Pulse generator / Ignition coil / Starting system / Starter / Starter click on
