Kawasaki KLR650 1987 – 2007 Clymer Owners Service and Repair Manual

book store
Softcover – 328 pages – Kawasaki KLR650 1987 – 2007 Clymer Owners Service Repair Manual covers Kawasaki KLR650 off-road motorcycles 1987 to 2007.Contents: QUICK REFERENCE DATA GENERAL INFORMATIONManual organization / Warnings cautions and notes / Safety / Warning labels / Serial numbers / Fasteners / Shop supplies / Basic tools / Precision measuring tools / Storage / Specifications TROUBLESHOOTINGOperating requirements / Starting the engine / Four-stroke operating principles / Engine spark test / Engine performance / Electrical testing / Starting system / Engine noise / Motorcycle noise / Engine leakdown test / Leak-down tester / Clutch / Gear shift linkage and transmission / Brakes LUBRICATION MAINTENANCE AND TUNE-UPPre-ride inspection / Break in / Engine oil and filter change / Fork oil change / Air filter / Cable lubrication / Drive chain cleaning and lubrication / Air filter housing draining / Muffler and spark arrestor cleaning / Balancer chain tensioner adjustment / Carburetor float chamber draining / Cooling system inspection / Drive chain adjustment / Throttle and clutch cable adjustment / Brake pedal adjustment / Idle speed and mixture adjustment / Engine timing check / Compression check / Spark plug plugs / Specifications ENGINE TOP ENDExhaust system / Cylinder head cover / Camshafts cam shafts camshaft shaft / Cam chain tensioner / Cylinder head / Valves / Cylinder / Piston / Piston rings / Specifications ENGINE LOWER ENDEngine removal installation / Cam chain lower guide / Left crankcase crank case cover / Engine balancer / Crankcase crank case / Seal replacement / Crankshaft crank shaft / Specifications CLUTCH / GEARSHIFT GEAR SHIFT LINKAGE AND LUBRICATION SYSTEMRight crankcase cover / Clutch / External gear shift linkage / Oil pump / Primary drive gear / Clutch cable replacement / Kick starter kickstarter / Specifications TRANSMISSION AND INTERNAL SHIFT MECHANISMInput shaft / Output shaft / Transmission inspection / Specifications FUEL SYSTEMCarburetor carb / Cleaning inspection adjustment / Float / Fuel valve / Evaporative emissions control system / Air filter housing / Specifications ELECTRICAL SYSTEMResistance testing / Continuity testing / Alternator / Stator and pickup pick up coil / Rotor and starter clutch / Starter / Ignition system / Lighting system / Fan / Water temperature gauge and sending unit / Turn signal relay / Start button / much more info
